GAF-1
Category:
Keyword:
Carbon nanotubes, Nanocomposites, New energy technology
Detailed introduction
图文详情
| Exterior | CNT diameter distribution （nm） |
Carbon nanotube length （μm） |
Purity （%） |
Non-carbon impurity content （%） |
Metal content（ppm） | Specific surface area （㎡/g） |
Moisture （ppm） |
|||||||||||||
| Fe | Co | Ni | ||||||||||||||||||
| GAF-1 | Black powder | 5~10 | 20~35 | Original powder | Pickling | High purity | Original powder | Pickling | High purity | Original powder | Pickling | High purity | Original powder | Pickling | High purity | Original powder | Pickling | High purity | 230~320 | ＜2000 |
| ≥ 90 |
≥ 98.5 |
≥ 99.9 |
≤ 10 |
≤ 1.5 |
≤ 0.1 |
<6000 | <300 | ≤50 | <1000 | <100 | <20 | <100 | <100 | <20 | ||||||
| Detection Method | Visually | After sample preparation, the samples were sent for SEM and TEM inspection. | High temperature calcination weight loss method | ICP-OES detection after sample preparation | JW-BK122W Static Nitrogen Adsorber | Moisture meter | ||||||||||||||
Advantage
GAF-1：High conductivity, bundled array carbon nanotubes, easy to form a conductive network, and high safety.
